TONE Impact Socket (6-Point, 3/8" Drive) 3NV Series
Sale price
$8.65
Regular price
$9.10
Lifetime Warranty: hand tools only
Description
An impact socket with an electroless-plated finish for better appearance and rust resistance. The O-ring parking groove lets you park the O-ring temporarily while fitting or removing the socket on the wrench, making the job easier.
Application: For tightening and loosening bolts and nuts.
Strong Drive 6-point profile. Patented.
Specifications
| Part Number | 3NV-06 to 3NV-24 |
|---|---|
| Drive size | 9.5 mm (3/8") |
| Tip type | 6-point |
| Size system | Metric |
| Replacement pin | P3016S |
| Replacement O-ring | RINGP16S |
| Finish | Electroless plating |
| Material | Structural steel |
Sizes
| Part Number | Size | Weight (g) | W × D × H (mm) |
|---|---|---|---|
| 3NV-06 | 6 mm | 30 | 19 × 19 × 27 |
| 3NV-07 | 7 mm | 30 | 19 × 19 × 27 |
| 3NV-08 | 8 mm | 30 | 19 × 19 × 27 |
| 3NV-09 | 9 mm | 35 | 19 × 19 × 29 |
| 3NV-10 | 10 mm | 35 | 19 × 19 × 29 |
| 3NV-11 | 11 mm | 40 | 19 × 19 × 29 |
| 3NV-12 | 12 mm | 40 | 19 × 19 × 29 |
| 3NV-13 | 13 mm | 45 | 20 × 20 × 29 |
| 3NV-14 | 14 mm | 50 | 21 × 21 × 31.5 |
| 3NV-15 | 15 mm | 50 | 22 × 22 × 31.5 |
| 3NV-16 | 16 mm | 60 | 24 × 24 × 31.5 |
| 3NV-17 | 17 mm | 60 | 25 × 25 × 31.5 |
| 3NV-18 | 18 mm | 65 | 26 × 26 × 35 |
| 3NV-19 | 19 mm | 85 | 28 × 28 × 35 |
| 3NV-21 | 21 mm | 90 | 29 × 29 × 35 |
| 3NV-22 | 22 mm | 95 | 30 × 30 × 35 |
| 3NV-23 | 23 mm | 110 | 32 × 32 × 35 |
| 3NV-24 | 24 mm | 110 | 33 × 33 × 35 |
Notes
Fit the correct size O-ring and pin securely before use. O-rings and pins are consumables; replace them when worn or deteriorated. Take care not to pinch your hands when taking tools in and out of the case.
Warranty: The TONE lifetime warranty applies to hand tools only.
