TONE Impact Socket (6-Point, 3/4" Drive) 6NV Series

An impact socket with an electroless-plated finish for better appearance and rust resistance. The O-ring parking groove lets you park the O-ring temporarily while fitting or removing the socket on the wrench, making the job easier.

Application: For tightening and loosening bolts and nuts.

Patented.

Specifications

Part Number	6NV-17 to 6NV-55
Drive size	19.0 mm (3/4")
Tip type	6-point
Size system	Metric
Replacement pin	P4033S
Replacement O-ring	RAS322S
Finish	Electroless plating
Material	Structural steel

Sizes

Part Number	Size	Weight (g)	W × D × H (mm)
6NV-17	17 mm	252	38 × 38 × 50
6NV-18	18 mm	258	38 × 38 × 50
6NV-19	19 mm	263	38 × 38 × 50
6NV-21	21 mm	270	38 × 38 × 50
6NV-22	22 mm	279	38 × 38 × 52
6NV-23	23 mm	283	38 × 38 × 52
6NV-24	24 mm	297	38 × 38 × 52
6NV-25	25 mm	325	40 × 40 × 55
6NV-26	26 mm	318	40 × 40 × 55
6NV-27	27 mm	338	42 × 42 × 55
6NV-28	28 mm	375	45 × 45 × 55
6NV-29	29 mm	367	45 × 45 × 55
6NV-30	30 mm	362	46 × 46 × 55
6NV-32	32 mm	376	48 × 48 × 55
6NV-33	33 mm	391	50 × 50 × 55
6NV-34	34 mm	463	52.5 × 52.5 × 58
6NV-35	35 mm	453	52.5 × 52.5 × 58
6NV-36	36 mm	453	54 × 54 × 58
6NV-38	38 mm	492	57 × 57 × 58
6NV-41	41 mm	498	60 × 60 × 58
6NV-46	46 mm	585	65 × 65 × 60
6NV-50	50 mm	616	70 × 70 × 60
6NV-55	55 mm	820	78 × 78 × 65

Notes

Fit the correct size O-ring and pin securely before use. O-rings and pins are consumables; replace them when worn or deteriorated.

Warranty: The TONE lifetime warranty applies to hand tools only.
