$440.00
Description
By adopting a twin hammer, there is little recoil and high power. The direction of the switch can be changed 360° (fixed every 45°) for excellent operability. Convenient for attaching and detaching bolts and nuts even in narrow spaces where work is difficult, such as automobile maintenance and assembly lines. Stepless output adjustment is possible by pulling the switch. Rotating joint to prevent hose kinking. Forward and reverse rotation can be switched.
Application: For working in narrow and difficult places.
Specifications
| Part Number | AR3120 |
|---|---|
| Right rotation maximum torque (N m) | 68 |
| Counterclockwise rotation maximum torque (N m) | 68 |
| Output angle | Output angle 9.5mm (3/8inch) |
| Tip shape | Square drive |
| Features | double rotation |
| No load speed (min-1[rpm]) | 500 |
| Working air pressure (MPa) | 0.62 |
| Joint thread diameter (mm) | Rc1/4 (PT1/4) |
| Air hose inner diameter (mm) | 10mm or more |
| Weight (g) | 800 |
| Dimensions (W × D × H, mm) | 196 × 41 × 60 |
Included Accessories
Plug: R1/4 (PT1/4), instruction manual
Notes
The tightening torque is a reference value. The torque value changes depending on the conditions.
